When it comes to constructing resilient, energy-efficient buildings, choosing the right building material is paramount. QuikBuild-3D Panels by Beardsell are two innovative solutions that have gained prominence in the construction industry.
Choosing the Right Prefabricated System for Your Build
Construction Solutions: Understanding QuikBuild-3D Panel
QuikBuild Panels are engineered structural insulated panels (SIPs) designed to streamline the construction process while enhancing energy efficiency and durability. These panels consist of an insulating foam core sandwiched between two layers of structural board, typically oriented strand board (OSB) or plywood.
Key Features:
Thermal Insulation
:
QuikBuild Panels: Feature a rigid foam core, typically EPS or XPS, providing high thermal insulation properties, EPS 3D Panels: Utilize expanded polystyrene (EPS) insulation, offering excellent thermal insulation with an R-value of 4-5 per inch.
Structural Strength
:
QuikBuild Panels: Offer exceptional structural integrity despite their lightweight construction, suitable for various environmental conditions,EPS 3D Panels: Incorporate a robust framework of welded wire mesh and EPS insulation, providing strong structural support and high durability.
Energy Efficiency
:
QuikBuild Panels: Maintain comfortable indoor temperatures and reduce heating and cooling expenses with their high thermal insulation and minimal air infiltration, EPS 3D Panels: Minimize heat transfer and energy consumption for heating and cooling purposes, contributing to overall energy efficiency.
Fire Resistance
:
QuikBuild Panels: Varies depending on the materials used; typically meet regulatory standards for fire protection, EPS 3D Panels: Known for their high fire resistance, enhancing building safety and meeting stringent fire protection requirements.
Installation
:
QuikBuild Panels: Prefabricated off-site for rapid installation, featuring an interlocking design for easy assembly and reduced labor costs,EPS 3D Panels: Also prefabricated off-site, allowing for quick and efficient on-site assembly with minimal labor requirements.
Versatility
:
QuikBuild Panels: Adaptable to various architectural designs and construction requirements, offering flexibility and customization options, EPS 3D Panels: Versatile and suitable for diverse projects, accommodating different design preferences and construction needs.
Thermal Insulation:
QuikBuild Panels: Feature a rigid foam core, typically EPS or XPS, providing high thermal insulation properties, EPS 3D Panels: Utilize expanded polystyrene (EPS) insulation, offering excellent thermal insulation with an R-value of 4-5 per inch.
Structural Strength:
QuikBuild Panels: Offer exceptional structural integrity despite their lightweight construction, suitable for various environmental conditions,EPS 3D Panels: Incorporate a robust framework of welded wire mesh and EPS insulation, providing strong structural support and high durability.
Energy Efficiency:
QuikBuild Panels: Maintain comfortable indoor temperatures and reduce heating and cooling expenses with their high thermal insulation and minimal air infiltration, EPS 3D Panels: Minimize heat transfer and energy consumption for heating and cooling purposes, contributing to overall energy efficiency.
Fire Resistance:
QuikBuild Panels: Varies depending on the materials used; typically meet regulatory standards for fire protection, EPS 3D Panels: Known for their high fire resistance, enhancing building safety and meeting stringent fire protection requirements.
Installation:
QuikBuild Panels: Prefabricated off-site for rapid installation, featuring an interlocking design for easy assembly and reduced labor costs,EPS 3D Panels: Also prefabricated off-site, allowing for quick and efficient on-site assembly with minimal labor requirements.
Versatility:
QuikBuild Panels: Adaptable to various architectural designs and construction requirements, offering flexibility and customization options, EPS 3D Panels: Versatile and suitable for diverse projects, accommodating different design preferences and construction needs.
Technical Data
| Specification | Details |
| Width | 1200 mm |
| Length | 2000~6000 mm |
| EPS Slab Thickness | 50, 80, 100, 120, 150 mm |
| EPS Slab Type | Plain or Corrugated |
| Mesh Spacing | 50 x 50 mm, 100 x 100 mm |
| Mesh Wire Thickness (dia) | 2.5 mm, 2.0 mm, 3.0 mm |
| Wall Panel | (2.5mm Wire, 50x50mm Mesh, 50mm EPS Panel + 1" plaster both sides) |
| Self Load | 120 kg/m2 |
| Load Bearing | 350 kN/m |
| Plaster Ratio | 1st Coat 15mm of 1:2:3 (Chips mix - 100% of size < 6mm) 2nd Coat 10mm of 1:5 (Cement/Sand only) |
| Roof Panel | (2.5mm Wire, 50x50mm Mesh, 80mm EPS Panel + 1" plaster + 3" concrete) |
| Self Load | 280 kg/m2 |
| Load Bearing | 10 kN/m2 |
| Concrete Ratio | 1:2:4 (Chips mix - 50% of size < 18mm + 50% of size < 10mm) |
